STATUS MPB20 [8/44] Operation

SWITCHING ON - SWITCHING OFF

Switching on: press ON/OFF switch (6).

Switching o: release ON/OFF switch (6).

This power tool is equipped with electric brake. The spindle stops rotating immediately

after releasing the switch lever.

OPERATION MODE SELECTION

Switching between the operation modes shall be performed only when the machine is

turned o.

Turn the mode selector switch (2) to the necessary position.

• Drilling - drilling in metal, wood, plastics, etc.

• Hammer drilling - hammer drilling in concrete, stone, etc.

• Hammer mode - chiselling grooves and demolishing in concrete, masonry, etc.

• Adjusting the chisel - to avoid operator’s fatigue, insert and x the chisel in the

necessary position.

INSERTING AND FASTENING SDS-PLUS BITS

Clean and grease the shank of the accessory, before placing it into the socket!

Insert the bit into the socket (1). Ensure that the socket grooves correspond to the bit shank

channels, and then press the bit inward until an audible “click” is heard.

To remove the bit, pull the sleeve backward, and then take the bit out.

ADJUSTING THE CHISEL POSITION

• Insert the chisel into the socket as it is described in section “Inserting SDS-Plus bits”.

• Turn the operating mode switch (2) in position «Adjusting the chisel».

• Rotate the tool by hand to the desired position.

• Turn the operating mode switch (2) to position «Hammer» and then turn the tool

slightly by hand left and right until locked.

• Longer operation life of the rotary hammer and higher eciency can be achieved only

with well sharpened tools for demolition and chiseling.

RECOMENDATIONS FOR OPERATION

Apply moderate pressure during drilling in concrete (approximately 80-100 N). Higher

pressure will not increase drilling eciency, but it will result in decreasing the operation life

of the machine.

Take the drill bit out of the opening from time to time to remove dust.

Watch out for the stage of blunting of the bit and change it if considerable decrease of

eciency is observed.

Do not operate the machine in «Hammer drilling» and «Hammer» mode with the switch (3)

in rightmost position.
