ROG Z690 Series BIOS Manual
13
2.4 AI OC Guide
• The screenshot shown in this section is for reference purposes only, and may not
exactly match what you see on your screen.
• This function is only enabled when using an unlocked CPU.
The AI OC Guide allows you to enable the Ai Overclocking feature, or view a quick guide
of the Ai Overclocking feature which highlights the recommended setup procedure and
descriptions of the AI Overclocking.
Clicking on Enable AI will enable AI Overclocking.
Click to view
the next topic in
the quick guide
Click to view the
previous topic in the
quick guide
Quick guide topics Click to go back
to main menu
Click to enable AI
Overclocking
