ROG Z690 Series BIOS Manual
57
Ramp Up Time
Allows you to set the maximum Ramp Up randomization time in micro ticks. This is for
acoustic noise mitigation Dynamic Periodicity Alteration (DPA) tuning. Use the <+> or <->
to adjust the value.
Configuration options: [0] - [255]
Ramp Down Time
Allows you to set the maximum Ramp Down randomization time in micro ticks. This is for
acoustic noise mitigation Dynamic Periodicity Alteration (DPA) tuning. Use the <+> or <->
to adjust the value.
Configuration options: [0] - [255]
IA VR Domain
Disable Fast PKG C State Ramp for IA Domain
This option needs to be configured to reduce acoustic noise during deeper C states.
[FALSE] Don’t disable Fast ramp during deeper C states.
[TRUE] Disable Fast ramp during deeper C state.
Slow Slew Rate for IA Domain
Set VR IA Slow Slew Rate for Deep Package C State ramp time; Slow slew rate equals
to Fast divided by number, the number is 2, 4, 8 to slow down the slew rate to help
minimize acoustic noise.
Configuration options: [Fast/2] [Fast/4] [Fast/8]
GT VR Domain
Disable Fast PKG C State Ramp for GT Domain
This option needs to be configured to reduce acoustic noise during deeper C states.
[FALSE] Don’t disable Fast ramp during deeper C states.
[TRUE] Disable Fast ramp during deeper C state.
Slow Slew Rate for GT Domain
Set VR GT Slow Slew Rate for Deep Package C State ramp time; Slow slew rate equals
to Fast divided by number, the number is 2, 4, 8 to slow down the slew rate to help
minimize acoustic noise.
Configuration options: [Fast/2] [Fast/4] [Fast/8]
CPU C-states
Allows you to enable or disable CPU Power Management. Allows CPU to go to C
states when it’s not 100% utilized.
Configuration options: [Auto] [Disabled] [Enabled]
The following items appear only when CPU C-states is set to [Enabled].
Enhanced C-States
Allows you to enable or disable C1E. When enabled, CPU will switch to minimum
speed when all cores enter C-State.
Configuration options: [Enabled] [Disabled]
Package C State Limit
Allows you to set the C-state limit for the CPU package. Setting to [Cpu Default]
will leave it as the Factory default value. Setting to [Auto] will initialize the deepest
available Package C State Limit.
Configuration options: [C0/C1] [C2] [C3] [C6] [C7] [C7s] [C8] [C9] [C10] [Cpu Default]
[Auto]
