20
ROG Z690 Series BIOS Manual
Performance Core Ratio
[Auto] The system will adjust all Performance core ratios automatically.
[Sync All Cores] Configure a core ratio limit to synchronize all Performance cores.
[By Core Usage] Configure the ratio limits for active cores depending on how many
Performance cores are being utilized.
[AI Optimized] Use AI to optimize the Performance core ratios.
• The [AI Optimized] item appears only when you use an unlocked CPU.
• The following item appears only when Performance Core Ratio is set to [Auto],
[Sync All Cores], or [By Core Usage].
Specific Performance Core
Performance Core0-7 Specific Ratio Limit
Configure a ratio limit for certain Performance Cores.
Performance Core0-7 Specific Adaptive Voltage
Allows configuration of the voltage supply to the CPU cores. Setting to [Auto] will
scale voltage according to the applied CPU core ratio. Do not confuse this setting with
VCCIN (CPU Input voltage).
Configuration options: [Auto] [Adaptive Mode]
The following item appears only when Performance Core0-7 Specific Adaptive Voltage
is set to [Adaptive Mode].
Offset Mode Sign
[+] Offset the CPU core voltage by a positive value.
[-] Offset the CPU core voltage by a negative value.
Performance Core0-7 Offset
Configure the CPU core voltage offset value. Use the <+> or <-> to adjust the value.
The values range from 0.001 V to 0.999 V with an interval of 0.001 V.
Configuration options: [Auto] [0.00100] - [0.99900]
You need to save the changes and reset the system for the changes to take effect.
Additional Turbo Mode CPU Core0-7 Voltage
Configure the amount of voltage fed to the CPU cores when running in the turbo
mode. Increase the voltage when configuring a High CPU core frequency. This
voltage will be affected by the offset value. Use the <+> or <-> to adjust the value. The
values range from 0.250 V to 1.920 V with an interval of 0.001 V.
Configuration options: [Auto] [0.25000] - [1.92000]
The following item appears only when Efficient Core Ratio is set to [Sync All Cores].
ALL-Core Ratio Limit
Ratio Limit for Efficient Cores when N Efficient cores are loaded. Use the <+> or <-> to
adjust the value.
Configuration options: [Auto] [8] - [50]
