32
ROG Z690 Series BIOS Manual
SA GV
System Agent Geyserville. Can disable, fix to a specific point, or enable frequency
switching. If enabled, we recommend you to leave options at parked values for best
compatibility. Enabling this feature requires a longer boot time.
Configuration options: [Disabled] [Enabled] [Fixed to 1st Point] [Fixed to 2nd Point]
[Fixed to 3rd Point] [Fixed to 4th Point]
The following items appear only when SA GV is set to [Enabled], [Fixed to 1st Point],
[Fixed to 2nd Point], [Fixed to 3rd Point], or [Fixed to 4th Point].
First Point Frequency
Allows you to specify the frequency for the given point. 0-MRC auto, else a specific
frequency as an integer: 2000Mhz.
Configuration options: [0] - [65535]
First Point Gear
Allows you to set the gear ratio for this SAGV point. 0-Auto, 1-G1, 2-G2, 4-G4.
Configuration options: [0] - [4]
Second Point Frequency
Allows you to specify the frequency for the given point. 0-MRC auto, else a specific
frequency as an integer: 2000Mhz.
Configuration options: [0] - [65535]
Second Point Gear
Allows you to set the gear ratio for this SAGV point. 0-Auto, 1-G1, 2-G2, 4-G4.
Configuration options: [0] - [4]
Third Point Frequency
Allows you to specify the frequency for the given point. 0-MRC auto, else a specific
frequency as an integer: 2000Mhz.
Configuration options: [0] - [65535]
Third Point Gear
Allows you to set the gear ratio for this SAGV point. 0-Auto, 1-G1, 2-G2, 4-G4.
Configuration options: [0] - [4]
The Fourth Point Gear will always be the settings you set in the main menu, so configure
the Fourth Point Gear there.
Digi+ VRM
Voltage Monitor
Configuration options: [Die Sense] [Socket Sense]
VRM Initialization Check
When any error occurs during VRM initialization, the system will hang at POST code
76/77 if this function is enabled.
Configuration options: [Disabled] [Enabled]
CPU Input Voltage Load-line Calibration
Configuration options [Auto] [Level 1] [Level 2] [Level 3]
