![Asus ROG MAXIMUS Z690 EXTREME [41/94] Tweaker s paradise](/img/pdf.png)
Asus ROG MAXIMUS Z690 EXTREME [41/94] Tweaker s paradise
![Asus ROG MAXIMUS Z690 EXTREME [41/94] Tweaker s paradise](/views2/1920436/page41/bg29.png)
ROG Z690 Series BIOS Manual
41
The following item appears only when Negative Ratio Offset A is set to [User Specify].
Ratio Offset
Use the <+> and <-> keys to adjust the value.
Configuration options: [0] - [31]
Temperature B
Package passing this temperature threshold will engage the negative ratio offset
specified in Negative Ratio Offset B. Unit in Degree Celsius. Use the <+> and <->
keys to adjust the value.
Configuration options: [Auto] [1] - [115]
Negative Ratio Offset B
This will be the potential negative offset to respective ratio when package temperature
rises above threshold specified in Temperature B.
Configuration options: [Auto] [User Specify]
The following item appears only when Negative Ratio Offset B is set to [User Specify].
Ratio Offset
Use the <+> and <-> keys to adjust the value.
Configuration options: [0] - [31]
V/F Point Offset
Offset Mode Sign 1-11
Configuration options: [+] [-]
V/F Point 1-11 Offset
Configuration options: [Auto] [0.001] - [0.999]
Tweaker’s Paradise
Initial BCLK Frequency
Allows you to set a different BCLK value during POST. May be useful for setting
a lower BCLK in scenarios where memory training is not stable at a higher BCLK
(a large frequency gap between BCLK Frequency and Initial frequency is not
recommended). Applies the same value as BCLK Frequency if left at default. Use
the <+> and <-> keys to adjust the value. The values range from 80.000MHz to
1000.000MHz with an interval of 0.050MHz.
Configuration options: [Auto] [80.0000] - [1000.00000]
BCLK Amplitude
Allows you to set the magnitude of the reference BCLK supplied to the processor.
Higher values may improve overclocking stability.
Configuration options: [Auto] [800mV] [900mV]
BCLK Slew Rate
Allows you set the speed at which the base clock rises or falls. Set a high value for
overclocking stability.
Configuration options: [Auto] [Slow] [Fast]
