ROG Z690 Series BIOS Manual

PCIE Frequency

Allows you to set the PCIe clock frequency. Use the <+> or <-> to adjust the value. The

values range from 80.0 MHz to 200.0 MHz.

Configuration options: [80.0] - [200.0]

The following item appears only when Ai Overclock Tuner is set to [ASUS Enhanced

Memory Profile].

AEMP

Allows you to select your ASUS Enhanced Memory Profile (AEMP). Each profile has its own

DRAM frequency, timing and voltage.

ASUS MultiCore Enhancement

[Auto - Lets BIOS Optimize] This item allows you to use ASUS optimized core ratio

Turbo settings at default processor speeds.

[Disabled - Enforce All limits] This item allows you to use Intel default Turbo core ratio

settings.

[Enabled - Remove All limits] This item allows you to use optimized power and current

thresholds for maintaining maximum performance.

SVID Behavior

Allows you to program the CPU’s SVID behavior based on the CPU’s quality. The default

option is based on [Typical Scenario], but the more optimistic the mode selected, the lower

the temperature of the CPU. [Intel’s Fail Safe] is the default behavior of the processor

oblivious to the actual Motherboard design. [Trained] optimizes SVID behavior to match

input parameters such as VRM Loadline and Target Frequencies.

Configuration options: [Auto] [Best-Case Scenario] [Typical Scenario] [Worst-Case Scenario]

[Intel’s Fail Safe] [Trained]

BCLK Frequency : DRAM Frequency Ratio

[Auto] The BCLK frequency to DRAM frequency ratio will be set to the optimized

setting.

[100:133] The BCLK frequency to DRAM frequency ratio will be set to 100:133.

[100:100] The BCLK frequency to DRAM frequency ratio will be set to 100:100.

Memory Controller : DRAM Frequency Ratio

BCLK Frequency: DRAM Frequency Ratio of 100:133 tends to overclock better and 1:2

Memory Controller: DRAM Frequency Ratio only works with even numbered DRAM Ratios

and not odd numbered ratios.

Configuration options: [Auto] [1:1] [1:2] [1:4]

DRAM Frequency

Allows you to set the memory operating frequency. The configurable options vary with the

BCLK (base clock) frequency setting. Select the auto mode to apply the optimized setting.

Configuration options: [Auto] [DDR5-800MHz] - [DDR5-13333MHz]
