ROG Z690 Series BIOS Manual

The following items appear only when CPU Core Ratio is set to [By Core Usage].

1-Core Ratio Limit / 2-Core Ratio Limit / 3-Core Ratio Limit / 4-Core Ratio

Limit / 5-Core Ratio Limit / 6-Core Ratio Limit / 7-Core Ratio Limit / 8-Core

Ratio Limit

The N-core ratio limit must be higher than or equal to the (N+1)-core ratio limit. (N stands for

the number of CPU cores) The core ratio limit cannot be set to [Auto] when the core number

is lower than N. The biggest core’s ratio limit must be lower than or equal to the second

biggest core’s ratio limit.

The following item appears only when CPU Core Ratio is set to [AI Optimized].

Optimized AVX Frequency

Select [Normal Use] for typical use cases, or select [Heavy AVX] for extreme loads such as

Prime 95 AVX.

Configuration options: [Normal Use] [Heavy AVX]

Efficient Core Ratio

[Auto] The system will adjust all Efficient core ratios automatically.

[Sync All Cores] Configure a core ratio limit to synchronize all Efficient cores.

[By Core Usage] Configure the ratio limits for active cores depending on how many Efficient

cores are being utilized.

[AI Optimized] Use AI to optimize the Efficient core ratios.

The following items appear only when Efficient Core Ratio is set to [Auto], [Sync All

Cores] or [By Core Usage].

Specific Efficient Core

Efficient Core Group0 Specific Ratio Limit

Configure a ratio limit for certain Efficient Cores. Use the <+> or <-> to adjust the

value.

Configuration options: [Auto] [8] - [120]

Efficient Core Group0 Specific Adaptive Voltage

Allows configuration of the voltage supply to the CPU cores. Setting to [Auto] will

scale voltage according to the applied CPU core ratio. Do not confuse this setting with

VCCIN (CPU Input voltage).

Configuration options: [Auto] [Adaptive Mode]

The following item appears only when Efficient Core Group0 Specific Adaptive Voltage

is set to [Adaptive Mode].

Offset Mode Sign

[+] Offset the CPU core voltage by a positive value.

[-] Offset the CPU core voltage by a negative value.
