ROG Z690 Series BIOS Manual
73
Voltage and Current Monitor
CPU Core Voltage, 12V Voltage, 5V Voltage, 3.3V Voltage, Memory Controller
Voltage [x.xxx V]
The onboard hardware monitor automatically detects the voltage output through the
onboard voltage regulators. Select [Ignore] if you do not want to detect this item.
CPU Core Current [xx A]
The onboard hardware monitor automatically detects the current output. Select
[Ignore] if you do not want to detect this item.
Q-Fan Configuration
AI Cooling
ASUS AI Cooling will automatically manage and control all motherboard fans,
ensuring the most efficient settings are set depending on the current system load and
temperature. When you enable this function, AI Cooling function will try to lower fan
speed to decrease fan noise without compromising current performance. You can
keep track of fan performance via the ASUS Fan Xpert software with a blue dot in the
Fan curve chart.
Configuration options: [Enabled] [Disabled]
Q-Fan Tuning
Click this item to automatically detect the lowest speed and configure the minimum
duty cycle for each fan.
The process may take 2 to 5 minutes. DO NOT shut down or reset your system during the
tuning process.
HYDRANODE Fan Association
The ASUS HYDRANODE function can be used to build up a communication platform
between the motherboard and other devices. For fan control, you can enjoy this
function when you use fans which support ASUS HYDRANODE, and will provide you
with more advanced fan control options. This function will be in effect when you use
compatible fans.
[Enabled] ASUS HYDRANODE fan function can be used.
[Disabled] Fans will not support the ASUS HYDRANODE fan function.
HYDRANODE Fan Reset
Click this item to reassociate all ASUS HYDRANODE fans when reconnecting or
replacing the fans.
CPU Q-Fan Control
Allows you to set the CPU Q-Fan operating mode.
[Auto Detect] Detects the type of installed fan/pump and automatically switches
the control modes.
[DC Mode] Enables the Q-Fan Control feature in DC mode for 3-pin fan/pump.
[PWM Mode] Enables the Q-Fan Control feature in PWM mode for 4-pin fan/
pump.
