2.5.3 Installing ASRock Polychrome SYNC Utility
Aer connecting the required LED strips, download the ASRockPolychrome SYNC Utility
from the ASRock Live Update & APP Shop. You can also download the utility from the
ASRock's website: "https://www.asrock.com". Go to the product page of your motherboard,
select "Support" > "Download" to download the ASRock Polychrome RGB.
Now you can adjust the RGB LED color through this utility and start coloring your PC
style your way!
Toggle on/o the
RGB LED switch
Sync RGB LED eects
for all LED regions of
the motherboard
Select a RGB LED light eect
from the drop-down menu.
Drag the tab to customize your
preference.
