65
AMD X670/B650 Series
Thunderbolt Support
[Enable] Select this item to enable the underbolt support.
[Disable] Select this item to disable the underbolt support.
Security Level
Allows you to select the Security Level.
Conguration options: [No Security] [User Authorization] [Secure Connect]
[Display Port only]
Debug Print In ASL
[Enabled] Select this item to enable Debug Print In ASL.
[Disabled] Select this item to disable Debug Print In ASL.
