35
AMD X670/B650 Series
VDDP Voltage
VDDP is a voltage for the DDR bus signaling (PHY), and it is derived from your DRAM
Voltage (VDDIO_Mem). As a result, VDDP voltage can approach but not exceed your DRAM
Voltage.
SoC/Uncore OC Voltage(VID)
Allows you to specify the SoC/Uncore voltage (VDD_SOC) to support memory and Innity
Fabric overclocking. VDD_SOC also determines the GPU voltage on processors with
integrated graphics.
VDD Misc Voltage
Allows you to congure the PCIe, DP Phy, PLL, ClkGen, and Pmux Supply.
DRAM VDDIO Voltage
Use this item to congure the VDDIO Voltage.
Seperate DRAM VDDIO Voltage Control
Allows you to congure the Seperate DRAM VDDIO Voltage control setting.
DRAM VPP Voltage
Allows you to congure the VPP Voltage supportewd by PMIC at DRAM side.
[Auto] Select this item to apply the default setting.
External Voltage Settings
Press [Enter] to congure the voltage options.
VDDCR_CPU Voltage
Input voltage for the processor by the external voltage regulator.
[Auto]
Select this item to apply the default VDDCR_CPU voltage setting.
[Oset Mode]
is mode allows you to congure the VDDCR_CPU voltage oset value.
[Fixed Mode]
is mode allows you to set a xed VDDCR_CPU voltage value.
VDDCR_CPU Load-Line Calibration
Load-Line is dened by Intel VRM Spec and aects the CPU power voltage. CPU Load-
Line Calibration helps prevent CPU voltage droop when the system is under heavy loading.
