39
AMD X670/B650 Series
1.8VSB Voltage
Allows you to congure the voltage for the 1.8VSB Voltage.
[Auto] Select this item to apply the default setting.
+1.05V_RUN Voltage
Allows you to congure the voltage for the +1.05V_RUN Voltage.
[Auto] Select this item to apply the default setting.
+1.05V_ALW Voltage
Allows you to congure the voltage for the +1.05V_ALW Voltage.
[Auto] Select this item to apply the default setting.
Save User Default
Type a prole name and press enter to save your settings as user default.
Load User Default
Loads previously saved user defaults.
Save User UEFI Setup Prole to Disk
Saves current UEFI settings as an user default prole to disk.
Load User UEFI Setup Prole to Disk
Loads previously saved user defaults from the disk.
