1
AMD X670/B650 Series
Chapter 1 Introduction
is user guide is a complete setup guide for all AMD X670 and B650 motherboard
series. e screenshots in this manual are for reference only. Settings and options
may vary due to the motherboard you purchased.
In this documentation, Chapter 1 gives an overview of the setup guide. Chapter 2
contains the operation guide of the soware and utilities. Chapter 3 contains the
conguration guide of the BIOS setup.
Soware Setup Guide
•
Auto Driver Installer (ADI)
•
ASRock Live Update & APP Shop
•
ASRock Motherboard Utility (A-Tuning)
•
ASRock Motherboard Utility (Phantom Gaming Tuning)
•
ASRock Polychrome SYNC
•
Nahimic Audio
BIOS Setup Guide
•
UEFI Setup Utility
Because the motherboard specications and the soware might be updated, the content of
this documentation will be subject to change without notice. In case any modications of
this documentation occur, the updated version will be available on ASRock’s website with-
out further notice. If you require technical support related to this motherboard, please visit
our website for specic information about the model you are using. ASRock website http://
www.asrock.com.
