safety
●
Never remove the lid until the cutting disc has completely
stopped.
●
Handle the cutting discs with care - they are extremely sharp
to use the cutting discs
1 Fit the drive shaft and bowl onto the power unit.
2 Holding by the centre grip , place the disc onto the
drive shaft with the appropriate side uppermost .
3 Fit the lid.
4 Choose which size feed tube you want to use. The
pusher contains a smaller feed tube for processing
individual items or thin ingredients.
To use the small feed tube - first put the large pusher
inside the feed tube.
To use the large feed tube - use both pushers
together.
5 Put the food in the feed tube.
6 Switch on and push down evenly with the pusher -
never put your fingers in the feed tube.
hints
●
Use fresh ingredients
●
Don’t cut food too small. Fill the width of the large feed tube fairly full. This
prevents the food from slipping sideways during processing. Alternatively use
the small feed tube.
●
When using the chipper disc, place ingredients horizontally.
●
When slicing or shredding: food placed upright comes out shorter than
food placed horizontally .
●
There will always be a small amount of waste on the plate or in the bowl after
processing.
citrus press
Use the citrus press to squeeze the juice
from citrus fruits (eg oranges, lemons, limes
and grapefruits).
cone
sieve
to use the citrus press
1 Fit the drive shaft and bowl onto the power
unit.
2 Add the sieve and turn clockwise until the
interlock fin on the sieve aligns with the line
on the outlet cover .
3 Place the cone over the drive shaft turning
until it drops all the way down .
4 Cut the fruit in half. Then switch on and
press the fruit onto the cone.
●
The citrus press will not operate if
the sieve is not locked correctly.
mill
Use the mill for milling herbs, nuts and coffee beans.
blade unit
sealing ring
jar
sprinkler lid
safety
●
Never fit the blade unit to your machine without the jar fitted.
●
Never unscrew the jar while the multi-mill is fitted to your
machine.
●
Don’t touch the sharp blades. Keep the blade unit away
from children.
●
Never remove the multi-mill until the blades have completely
stopped.
important
●
To ensure long life of your mill, never run for longer than 30
seconds. Switch off as soon as you’ve got the right consistency.
●
Don’t process spices - they may damage the plastic.
●
The machine won’t work if the mill is fitted incorrectly.
●
Use for dry ingredients only.
to use your mill
1 Put your ingredients into the jar. Fill it no more than half full.
2 Fit the sealing ring into the blade unit.
3 Turn the blade unit upside down. Lower it into the
jar, blades down.
4 Screw the blade unit onto the jar until it is finger
tight.
5 Remove the liquidiser outlet cover by turning in an
anti clockwise direction.
6 Place the mill on the liquidiser outlet and turn to lock
in a clockwise direction .
7 Switch on to maximum speed or use the pulse
control.
8 After milling, you can replace the blade unit with the
sprinkler lid and shake out your food.
●
The sprinkler lid is not airtight.
hints
●
Herbs are best milled when clean and dry.
KENSTORE™ attachments carousel
Your food processor is supplied with an attachment storage carousel that fits
inside the bowl.
to use the storage carousel
1 Fit the knife blade to the bowl.
2 Then fit the whisk, discs and canopy into the carousel .
3 Fit the carousel over the knife blade and place the processor lid on top
4
