Chapter 1. Introduction
5
Components
Top View
No. Component Description
Audio Section (Controls the audio settings of the system)
1 audio level control Controls the volume of the audio source selected.
2 volume meter The LED reflects the controlled volume.
During firmware upgrade, the LED behavior is changed.
Refer to Upgrading the Unit on page 69 for the LED
behavior during firmware upgrade.
3 MIC / Line-in
selector
Switches between the MIC / Line-in audio source.
The button is lit when switched to this source.
4 MIC / Line-in audio 1 Switches to the MIC / Line-in audio 1 source.
The button is lit when switched to this source.
5 MIC/Line-in audio 2 Switches to the MIC / Line-in audio 2 source.
The button is lit when switched to this source.
6 HDMI 1 audio
source
Switches to the HDMI 1 audio source.
The button is lit when switched to this source.
TUSFBN JOHUSBOTJUJPO T
HP!MJWF
4
8
5
9
BVUPDVU
BVEJP
2
BVEJP
3
BVEJP
TSD
QH N
TDFOFT
IENJ
2
IENJ
4
BGW
BGW
BGW
BGW
IENJ
3
MJOF
JO
IENJ
5
2
6
3
7
QHN
NVUF
11
12 13 14 15
16
17
1819
20
8
2
3
4
5
6 7
1
9
10
