StreamLIVE™ PRO User Manual
54
Others
Component Description
Pause
Pause picture is the display when the streaming is paused. You can
select black, the pause logos, or upload your own custom logo.
Transition
Period
This is the scene transitioning delay for the Auto button (on the app or
on the unit). Choose between 0.3 and 3 seconds. (Refer to Transition
Control on page 37 for the Auto button behavior)
USB Cable
Network
Sharing
Enable to allow the iPad to share internet connection with the
StreamLIVE™ PRO. This may also increase the internet traffic between
the StreamLIVE™ PRO and the iPad itself.
