Chapter 1. Introduction
9
Side View
No. Component Description
1 iPad link port (data
only)
Connects to the iPad for ATEN OnAir app.
2 3.5mm audio
monitor jack
Sound output for the PGM scene (the redly lit scene).
MJOL
