StreamLIVE™ PRO User Manual
58
Recording Live-stream Video (External Storage)
Before you start recording the live-stream videos, make sure that you have a
storage device ready to start and is connected to the StreamLIVE™ HD.
Recording live-streams requires a USB 3.0 or later storage device. It is
HIGHLY recommended that you use an external hard drive (with at least 32GB
worth of storage).
When you first connect the storage device, the ATEN OnAir PRO app will
verify its format and USB spec. If the format is not desirable, the ATEN OnAir
PRO app will ask if you would like to format it. Make sure the files in the
storage device are backed up before you format it.
When the format is desirable, you can start recording your live-stream.
External Storage Settings
Enable the External Storage ( ) by plugging a USB3.0 USB storage device
to the USB 3.1 Gen1 Type-A port (storage only) located on the StreamLIVE™
PRO’s rear panel.
A warning message appears if there is no USB3.0 or later storage device
plugged into the StreamLIVE™ PRO.
JOQVU!2JOQVU!3
PV UQV UMP PQ!PVU
IE N J2191Q WJEFPIE N J5L WJEFP
TSD 0QH N
BV EJP!2
BV EJP!3
JOQVU!4JOQVU!5
QP X FS
ED23W
VTC
TUP SBHF
N JD 0MJOFJO
For Live-stream Video Recording
