StreamLIVE™ PRO User Manual
14
Connecting iPad
iPad with Lightning Connector
For iPads with lightning connectors, using the USB-C to USB Type-A cable
included, connect its USB-C end to the StreamLIVE™ PRO and its USB-A
end to an Apple Lightning to USB 3 Adapter (not included, may need
additional purchase), which shall connect to your iPad.
If you wish to have the charging function, connect your lightning charging
cable to the Apple Lightning to USB 3 Adapter.
iPad with USB-C Connector
For iPads having USB-C connectors, simply connect the USB-C to USB-C
cable included between your iPad and the StreamLIVE™ PRO.
