35
Chapter 4
ATEN OnAir PRO App & Video Mixer
Video Mixer
The video mixer page allows you to preview videos of PRV and PGM, adjust
MIC and PGM volume, scene selection and editing, and transition control.
The components of the page is shown below:
No. Component Description
1 PRV
Preview
The preview scene.
