Chapter 4. ATEN OnAir PRO App & Video
39
Scene Editor
When you tap the icon under a scene in the scene selector region, you can
start editing the scene’s display.
An example is shown below:
No. Component Description
1 Scene Display This region is how this scene will be displayed. You can
configure the components within the region.
2 Resize/Crop
tool
Tap to resize/crop the selected item.
Refer to Resize/Crop Tool on page 42 on how to use this
function.
