StreamLIVE™ PRO User Manual

3 Overlay Edit overlay in this region. You can Delete, Edit, and

Show/Hide Overlay.

1. Select a Scene or the Overlay: Tap to select a scene for

the copied overlay.

2. Delete: Tap to delete.

3. Edit: Tap to edit.

4. Show/Hide Overlay: Tap to show or hide

You can also re-order the overlays to determine which

overlay is to be displayed on top. Refer to Re-order the

Overlays, page 45 for more details.

4 Media Select the source(s) and how the source(s) are laid out for

the scene.

1. Full Screen Mode

2. Dual View: Dual View Mode (Picture-in-Picture or

Picture-by-Picture).

3. Background: Plain Background.

5 Add Text

Overlay

Tap this icon to add a text overlay. Refer to Add/Edit Text

Overlay on page 44 below for more information.

To edit the location and size of the overlay, select the

overlay in the “Overlay” region and configure in the “Scene

Display” region.

The added overlay will appear in the “Overlay” region.

Up to 30 text overlays (layers) are support per scene.

6 Add Image

Overlay

Tap this icon to add an image overlay.

Tapping allows you to add an Image Overlay. iPad will

flip to the Photos page for you to select an image. Select

the image and tap OK.

To relocate, tap and hold the overlay to drag.

To resize, refer to Resize/Crop Tool on page 42.

The added overlay will appear in the “Overlay” region.

Up to 5 image overlays (layers) are support per scene.

7 Switch Video

Source (Dual-

View)

During dual-view, tapping this button switches video source

position between 1 and 2.

No. Component Description
