StreamLIVE™ PRO User Manual
86
Audio Output HDMI Outputs (Stereo)
1 x 1/8” Phone Jack (Stereo)
Network Protocol Dual-stream encoder supports direct live streaming to CDN
server over Ethernet using Real Time Messaging Protocol
(RTMP/RTMPS)
Video Encoding
Format: H.264
Bit rate: 512 Kbps - 10 Mbps
Color Format: YUV420
Resolution: 1080p 30 / 25, 720p 60 / 50 / 30 / 25, 480p 60 /
50 / 30 / 25
Audio Encoding
Format: AAC
Sampling Rate: 48 kHz
Bit rate: 128 kbps
Recording Storage Max. Video Resolution: 1080p 30 / 25
File Format: MP4
Support Media: USB 3.x compatible mobile drive (HDD/
SSD) with at least 32 GB of free space
Connection 2 x USB 3.1 Gen1 Type-A Female (Blue)
1 x USB-C
1 x GbE LAN Port
Environmental
Operating Temperature 0 – 40 ºC
Storage Temperature –20 – 60 ºC
Humidity 0–80% RH, Non-Condensing
Function StreamLIVE™ PRO
