MAINTENANCE SERVICE it takes a short time for the hammer mechanism to reach full impact power best hammer drilling results can be obtained by only a slight pressure on the tool needed to keep the automatic clutch engaged drilling performance will not improve by applying more pressure on the tool Normal drilling screwdriving For drilling in wood metal and plastic as well as for screwdriving use adapter J clean and lightly lubricate adapter before insertion pull back locking sleeve G and insert adapter in SDS chuck while turning and pushing it until it engages the adapter locks in position automatically pull adapter to check whether is it locked correctly set switch E to normal drilling only activate when tool is switched off and plug is disconnected Chiseling with rotating chisel I switch off the tool and disconnect the plug select rotating chiseling mode Chiseling with fixed chisel I switch off the tool and disconnect the plug select rotating chiseling mode place chisel in desired position select fixed chisel ing m ode Changing bits ns I clean and lightly lubricate the SDS accessory before insertion pull back locking sleeve G and insert accessory in SDS chuck while turning and pushing it until it engages the accessory locks in position automatically pull accessory to check that it is locked correctly rem we accessory by pulling back locking sleeve G the SDS accessory requires freedom of movement which causes eccentricity when tool Is off load however the accessory automatically centres Itself during operation without affecting drilling precision I do not use bits chisels with a damaged shank I only use sharp bits chisels Safety clutch If the accessory gets jammed the drive to the spindle is interrupted causing a rattling noise immediately switch off tool rem we the jammed accessory switch on tool again Adjusting drilling depth Holding and guiding the tool I while working always hold the tool at the grey coloured grip area s always use auxiliary handle H can be adjusted as illustrated keep the ventilation slots uncovered do not apply too much pressure on the tool let the tool do the work for you Always keep tool and cord clean especially the ventilation slots I disconnect the plug before cleaning If the tool should fail despite the care taken in manufacturing and testing procedures repair should be carried outby an after sales service centre for SKIL power tools send the tool undismantled together with proof of purchase to your dealer or the nearest SKIL service station addresses as well as the service diagram of the tool are listed on www skilmasters com ENVIRONMENT Do not dispose of electric tools accessories and packaging together with household waste material only for EU countries in observance of European Directive 2012 19 EC on waste of electric and electronic equipment and its implementation in accordance with national law electric tools that have reached the end of their life must be collected separately and returned to an environmentally compatible recycling facility symbol will remind you of this when the need for disposing occurs DECLARATION OF CONFORMITY C We declare under our sole responsibility that the product described under Technical data is in conformity with the following standards or standardization documents EN 60745 EN 61000 EN 55014 in accordance with the provisions of the directives 2004 108 EC 2006 42 EC 2011 65 EU Technical file at SKIL Europe BV PT SEU ENG1 4825 BD Breda NL Marijn van der Hoofden Operations Engineering Olaf Dijkgraaf Approval Manager SKIL Europe BV 4825 BD Breda NL 10 03 2014 NOISE VIBRATION Measured in accordance with EN 60745 the sound pressure level of this tool is 92 dB A and the sound power level 103 dB A standard deviation 3 dB and the vibration hand arm method uncertainty K 1 5 m s2 when hammer drilling in concrete 16 8 m s2 when chiseling 13 7 m s2 The vibration emission level has been measured in accordance with a standardised test given in EN 60745 it may be used to compare one tool with another and as a preliminary assessment of exposure to vibration when using the tool for the applications mentioned using the tool for different applications or with different or poorly maintained accessories may significantly increase the exposure level APPLICATION ADVICE When drilling ferrous metals pre drill a smaller hole when a large hole is required lubricate drill bit occasionally with oil When turning in a screw at near the cross cut end or an edge of wood pre drill a hole in order to avoid cracking of the wood 8
