Getting Started22
1 Find the VCR Plus+ Channel Listing in your program guide. For
details, see page 33.
2 For unscrambled channels, if the channels in the program guide are
different from the channels that you actually use on your TV, set the
channels that are different as follows. For details, see page 34.
1 Press MENU and select SET VCR Plus+
CHANNELS.
MENU
TIMER SET / CHECK
TUNER PRESET
CLOCK SET
SET VCR Plus+ CHANNELS
ADVANCED OPTIONS
SELECT : [ ]
SET : [ EXECUTE ]
3 For scrambled channels, enter all the scambled channels you want to
record and the cable box output channel (usually 2, 3, or 4). For details,
see page 34.
1 Press MENU and select SET VCR Plus+
CHANNELS.
SET VCR Plus+ CHANNELS
GUIDE
Or, push [ EXECUTE ] to see
CH TV CH
25 – 3
Push 0–9 keys to set
Program GUIDE CH
VCR Plus+ CHANNEL LIST
SET VCR Plus+ CHANNELS
GUIDE
Or, push [ EXECUTE ] to see
CH TV CH
25 – 15
Push 0–9 keys to set
Program GUIDE CH
VCR Plus+ CHANNEL LIST
Hookup 4: VCR Plus+ channel setup
2 Enter the program guide channel, then the cable
box output channel.
Program guide channel
2 Enter the program guide channel, then the
channel you use on your TV.
3 Press EXECUTE.
Cable box output channel
MENU
TIMER SET / CHECK
TUNER PRESET
CLOCK SET
SET VCR Plus+ CHANNELS
ADVANCED OPTIONS
SELECT : [ ]
SET : [ EXECUTE ]
Step 3: Hookups (continued)
Program guide channel
Your actual TV channel
