53
Additional Operations
Menu option
AUTO ANT SEL
AUTO STEREO
DIMMER
AUDIO MIX
NORMAL AUDIO
APC
ADVANCED OPTIONS
AUTO ANT SEL
DIMMER
AUDIO MIX
ON
ON
•
•
OFF
OFF
ON OFF
SELECT
SET
:
:
[]
[]
AUTO STEREO
NORMAL AUDIO
APC
•
ON OFF•
MAIN SAP•
ON OFF•
1 Press MENU and select ADVANCED
OPTIONS.
2 Press CURSOR >/. to select the option to change, then press CURSOR
?// to change the setting.
3 Press EXECUTE to return to the original screen.
Changing menu options
Menu choices
Initial settings are indicated in bold print.
Set this option to
ON if your TV is connected only to VHF/UHF OUT on the VCR.
To play a tape , set the TV to the VCR channel (channel 3 or 4).
OFF if your TV is connected to both VHF/UHF OUT and LINE
OUT on the VCR. To play a tape, set the TV to the VCR input.
ON to receive stereo programs, OFF to reduce noise. The sound
changes to monaural.
ON to make the display window dim, OFF to make it brighter.
ON to listen to the sound recorded on hi-fi and normal audio
tracks at the same time. The AUDIO MONITOR button will not
function.OFF to listen to hi-fi and normal audio tracks separately.
Select the sound using the AUDIO MONITOR button.
MAIN to record the main sound on both hi-fi and normal audio
tracks.SAP to record the SAP (Second Audio Program) sound on
the normal audio track. The main sound is recorded on the hi-fi
audio track.
ON to switch on the APC (Adaptive Picture Control) function and
improve picture quality, OFF to switch off APC.
