MENU
TIMER SET / CHECK
TUNER PRESET
CLOCK SET
SET VCR Plus+ CHANNELS
ADVANCED OPTIONS
SELECT : [ ]
SET : [ EXECUTE ]
ADVANCED OPTIONS
AUTO ANT SEL
DIMMER
AUDIO MIX
ON
ON
•
•
OFF
OFF
ON OFF
SELECT
SET
:
:
[]
[]
AUTO STEREO
NORMAL AUDIO
APC
•
ON OFF
•
MAIN SAP•
ON OFF•
A/V hookup: VCR setup
Press MENU and select
ADVANCED OPTIONS.
Set AUTO ANT SEL to
OFF and press EXECUTE.
For details, see
page 53.
Caution
Connections between the VCR’s VHF/UHF connector and the antenna terminals of
the TV receiver should be made only as shown in the following instructions. Failure to
do so may result in operation that violates the regulations of the Federal
Communications Commission regarding the use and operation of RF devices. Never
connect the output of the VCR to an antenna or make simultaneous (parallel) antenna
and VCR connections at the antenna terminals of your receiver.
Note to CATV system installer
This reminder is provided to call the CATV system installer’s attention to Article 820-
40 of the NEC that provides guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected to the grounding system of the
building, as close to the point of cable entry as practical.
After you’ve connected your TV and completed antenna or cable hookup,
use the following procedure to set up the VCR.
