Basic Operations36

Basic Operations

Playing a tape

1 Turn on your TV and set it to the video channel.

2 Insert a tape.

The VCR turns on and starts playing

automatically if you insert a tape with its

safety tab removed.

3 Press · PLAY.

When the tape reaches the end, it will rewind automatically.

6 EJECT

COUNTER

RESET

DISPLAY

P PAUSE

· PLAY

p STOP

DUAL MODE

SHUTTLE

ring
