BEST Arctic [12/40] English

English

! The appliance must be installed by a qualified person

in compliance with the instructions provided.

Wear gloves when carrying out installation and

maintenance operations.

In order to optimize energy consumption, high speed of

work signaled by red LEDs (L) will be automatically

reduced to standard speed after 5 minutes of work.

- If the hood is left on (lights and/or motor), after 10

hours in the absence of commands from the user, it

will automatically switch to OFF condition with all

services switched off.

- The Buzzer emits a “beep” each time that a

command is set from the keyboard or remote control

(optional).

- In the event of interruption of power during the hood,

if you restore the hood in the OFF state, then the

engine must be reactivate manually.

If the supply cord is damaged, it must be replaced by

the manufacturer, its service agent or similarly qualified

persons in order to avoid a hazard.

AIR VENT

(for ducting versions)

! Prepare the hole and the air vent duct (150 mm

diameter).

! Use a duct of the minimum indispensible length.

! Use a duct with as few elbows as possible (maximum

elbow angle: 90°).

! Avoid drastic changes in the duct cross-section.

! Use a duct with an as smooth as possible inside.

! The duct must be made of certified material.

! Do not connect the hood to smoke exhaust ducts for

the products of combustion (boilers, fireplaces,

stoves, etc).

! For the air vents comply with the provisions laid down

by the competent authorities.

In addition, the air must not be evacuated through a

hole in the wall unless specifically intended for this

purpose.

! Fit air intakes in the room to prevent the hood from

creating a negative pressure in the room (which must

not exceed 0.04 mbar); if the hood is used at the

same time as non-electrical equipment (gas-, oil- and

charcoal-fired stoves, etc.) the exhaust gas may be

sucked in by the heat source.

FILTERING OR DUCTING VERSION ?

The hood may be in filtering or in ducting version.

Decide from the outset which type is to be installed.

For better efficiency, we recommend installing the hood

in the ducting version (if possible).

Ducting version

The hood purifies the air and evacuates it to the outside

through an exhaust duct (diameter 150 mm).

Filtering version

The hood purifies the air and recycles the clean air

back into the room.

CONTROLS

A = Stand-by/OFF

When the chimney cooker hood is on, only this button

will be backlit. Pressing the button will activate Stand-by

mode. If the chimney cooker hood has not received

commands in following 5 minutes, the Stand-by mode

will turn off. In Stand-by mode, button A will light, and

buttons B,C, and F will only be backlit.

When the chimney cooker hood is turned on, pressing

and holding the button (> 2") will turn off the device

(engine, lights, and timer, if it is on).

Cleanup Mode:

Before cleaning the chimney cooker hood, make sure

that the chimney cooker hood is turned off (only button

A should be backlit). Pressing and holding the button (>

2") will turn on/off working mode for 3 minutes: during this

time the chimney cooker hood must not receive any

commands (all buttons are only backlit).

B = lights ON/OFF button. Pressing and holding the

button (> 2") will turn on/off accessary lighting (only

available in certain models).

C = engine ON/OFF button. When the engine is not

working, pressing the button will turn on the first speed

mode of the engine (lighting slider L area). When the

engine is working, pressing this button will turn off the

engine.

D = Lower engine speed button

E = Increase engine speed button

L = Slider area for engine speed. Sliding finger on this

area (i.e. pressing and sliding finger) will increase or

lower engine speed. High speed is signaled by red.

F = Timer. In order to turn the Timer on, an appropriate

button should be pressed. Engine will stop automatically

after 5 minutes (button blinks rapidly). Pressing the

button when the 5-minute Timer is on will turn on the 10-

minute Timer (button blinks slowly). In order to turn the

Timer off, press and hold the button (> 2").

G = Anti-grease filter (filters) alert. After 30 hours of

chimney cooker hood work, the necessity to clean anti-

grease filters will be signaled by backliting this button. In

order to reset work time, press and hold the button (> 2").

H = Charcoal filter (filters) alert. After 120 hours of

chimney cooker hood work, the necessity to clean

A B

C D

E F

G H
