9
UK
- Instruction on mounting and use
Consult the designs in the front pages referenced in the text
by alphabet letters.
Closely follow the instructions set out in this manual.
All
responsibility
, for any eventual inconveniences, damages or
manual, is declined.
Note:
the elements marked with the symbol “(*)” are optional
purchase
, not supplied.
Use
version.
Ducting version
The hood is equipped with a top air outlet
B for discharge of
fumes to the outside (exhaust pipe and pipe fixing clamps no
t
provided).
Fig. 5-6
Attention!
removed.
Filter version
When there is no exhaust duct for venting outdoors, you can
use a carbon filter.
The air is depurated by the filter and put again in the
su
rrounding. To use the appliance in this version, proceded as
follows:
Attention!
be ordered and mounted.
Installation
The minimum distance between the supporting
surface for the
65cm from gas or mixed cookers.
If the instructions for installation for the gas hob specify a
greater distance, this mus
t be adhered to.
Electrical connection
The mains power supply must correspond to the rating
indicated on the plate situated inside the hood. If provided with
a plug connect the hood to a socket in compliance with
current
regulations and positioned in an accessible area. If it not fitted
with a plug (direct mains connection) or if the plug is not
located in an accessible area apply a bi
-polar switch in
accordance with standards which assures the complete
disconnecti
on of the mains under conditions relating to over-
current category III, in accordance with installation
instructions.
IMPORTANT:
Before re-connecting the hood circuit to the
mains supply and checking the efficient function, always
check that the mains cabl
e is correctly assembled and that it
has NOT remained crushed inside the compartment of the
same during the installation stage.
Mounting
Before beginning installation:
• Check that the product purchased is of a suitable size
for
the chosen installation area.
•
To facilitate installation, remove the fat filters and the
other parts allowed and described here, dismantle and
mount it.
To remove see also the relative paragraphs.
• Remove the active carbon (*) filter/s if supplied
(see also
relative paragraph). This/these is/are to be mounted only
if you want lo use the hood in the filtering version.
•
Check (for transport reasons) that there is no other
supplied material inside the hood (e.g. packets with
screws (*), guarantees (*)
, etc.), eventually removing
them and keeping them.
• If possible, disconnect and move freestanding or slide-
in
range from cabinet opening to provide easier access to
rear wall/ceiling. Otherwise put a thick, protective
covering over countertop, cooktop or
range to protect
from damage and debris. Select a flat surface for
assembling the unit. Cover that surface with a protective
covering and place all canopy hood parts and hardware
in it.
•
Disconnect the hood during electrical connection, by
turning the home mains switch off.
•
In addition check whether near the installation area of the
hood (in the area accessible also with the hood mounted)
an electric socket is available and it is possible to
connect a fumes discharge device to the outside (only
suction version).
•
Carry out all the masonry work necessary (e.g.
installation of an electric socket and/or a hole for the
passage of the discharge tube).
Expansion wall plugs are provided to secure the hood to most
types of walls/ceilings. However, a qualified
technician must
verify suitability of the materials in accordance with the type of
wall/ceiling. The wall/ceiling must be strong enough to take
the weight of the hood.
Do not tile, grout or silicone this
appliance to the wall. Surface mounting only.
Fig. 5-6
•
Trace a central line on the wall in order to ease mounting
(1
), position the hole template in a way that the middle
line printed on top corresponds to the central line marked
previously and the lower side of the mask corresponds to
the lower part of the hood once mounted. (2).
•
Make 3 holes Ø 8 mm with a drill and fix the support
bracket with two dowels and screws to the wall (3),
insert
the third dowel into the lower hole.
• Apply the support bracket „G“
to the adherent ceiling,
use the chimney supp
ort bracket as a hole scheme (if
present, the small eyelet found on the support should
coincide with the line previously traced on the wall) and
trace with a pencil 2 holes, drill the holes (Ø8mm), insert
2 plugs.
Fasten the support bracket to the wall
with 2 5x45mm
