Zoom H1n Limited Edition [18/71] Preventing misoperation

Preventing misoperation

Misoperation during recording can be prevented by using the HOLD function to disable use of the buttons.

Activating the HOLD function

1. Slide to HOLD.

Deactivating the HOLD function

1. Slide back to the middle.
