Zoom H1n Limited Edition [48/71] Enabling direct monitoring

Enabling direct monitoring

This directly outputs the input signal from the before sending it to the computer or iOS device.

This

enables monitoring without latency

1. During audio interface operation, while pressing , press to turn it ON.
