Zoom H1n Limited Edition [31/71] Monitoring recording

Monitoring recording

The sound being recorded can be monitored using headphones.

1. Connect headphones to the PHONE/LINE OUT jack on the .

2. Press and to adjust the monitoring volume.

HINT

The monitoring volume can be set from 0 to 100.
