Zoom H1n Limited Edition [64/71] Restoring default setting values

Restoring default setting values

The settings can be restored to their factory defaults.

1. While pressing , turn the power on.

This opens the SETTING screen.

2. Use and to select "Factory Reset", and press .

3. Use and to select "Execute", and press .

This starts resetting the .

After the settings are reset, the power will automatically turn o.

NOTE

Input level settings will not be reset.
