10. THE SEQUENCER
28
• Note trigs trigger sounds or MIDI notes.
• Lock trigs triggers parameter locks, but without triggering notes.
Note trigs are indicated by red [TRIG] keys and lock trigs are indicated by yellow [TRIG] keys. Unlit
[TRIG] keys indicate steps that does not contain any trigs. Read more about parameter locks in section
“10.11.1 PARAMETER LOCKS” on page 33. The two types of trigs are added dierently in the sequenc-
er, depending on whether GRID RECORDING or LIVE RECORDING mode is active.
10.2.2 GRID RECORDING MODE
GRID RECORDING is a method of composing where you use the [TRIG] keys to add trigs.
1. Enter GRID RECORDING mode by pressing the [RECORD] key. The [RECORD] key lights up red to
indicate that GRID RECORDING mode is active.
2. Select the track to which you want to add trigs by pressing and holding [TRACK] and then one of
the [TRIG] keys. A red [TRIG] key indicates the active track.
3. Place note trigs on the sequencer using the sixteen [TRIG] keys. To add a lock trig, press [FUNC-
TION] and [TRIG]. Lock trigs may be entered on any step of the sequencer, including ones that
contains note trigs. Quickly pressing the [TRIG] key of any of the trigs entered will remove the trig.
Pressing a [TRIG] key of a trig and holding it slightly longer will prepare the trig for editing, rather
than removing it.
4. Select another track, and add note trigs and lock trigs. Repeat the procedure for all the tracks you
want to use.
5. Press [PLAY] to listen to the sequence.
Add micro timing to a note trig by pressing and holding the [TRIG] key while pressing [ARROW] keys
[LEFT] or [RIGHT]. For more information, please see “10.3 MICRO TIMING MENU” on page 29.
Set the retrig speed by pressing and holding the [TRIG] key while pressing [ARROW] keys [UP] or
[DOWN]. Similarly, a pop-up menu will appear on the screen, where various retrig settings are made.
For more information, please see “10.4 RETRIG MENU” on page 29.
If the pattern contains more than 16 steps, select the pattern page you want to edit by pressing the
[PAGE] key. A fully lit <PATTERN PAGE> LED shows the active pattern page.
Press [RECORD] to exit the GRID RECORDING mode.
• You can use an external MIDI controller such as a keyboard to input NOTE and TRIG
VELOCITY data when you are in GRID RECORDING mode. Just press and hold a [TRIG]
key, and then play a note on the external keyboard. On MIDI tracks, you can add up to a
four note chord to every trig. The first note sets the TRIG VELOCITY value for all notes
on the trig.
• All trigs of a track can be shifted forwards or backward on the sequencer. While in GRID
RECORDING mode, hold down [FUNC] while pressing the [LEFT] or [RIGHT] arrow
keys to perform the trig shift.
10.2.3 LIVE RECORDING MODE
LIVE RECORDING mode is the second method of adding trigs to the tracks. In this recording mode, the
[TRIG] keys are played in real time to input trigs to the tracks. You can also use CHROMATIC mode to
add note trigs chromatically. It is also possible to enter parameter locks in real time. Trigs input in LIVE
RECORDING mode can be automatically quantized or not. Non-quantized trigs can be quantized after
they are recorded, by using the QUANTIZE menu that is accessed by pressing [FUNC] + [TRIG]. For
more information, please see “10.7 QUANTIZE MENU” on page 31.
1. Press and hold [RECORD], then press [PLAY] to enter LIVE RECORDING mode. Quickly pressing
[PLAY] twice while keeping the [RECORD] key pressed will activate/deactivate automatic quantiza-
tion of LIVE RECORDING. The sequencer starts to play, and the [RECORD] key starts to flash red.
2. Enter trigs in real time by tapping the [TRIG] keys. If CHROMATIC mode is active, the pitch value of
the note trig will be recorded according to which [TRIG] key is pressed. Any changes to PARAMETER
page settings, using the DATA ENTRY knobs, will be recorded as parameter locks and add lock trigs
where needed.
3. Press [PLAY] to exit LIVE RECORDING mode while keeping the sequencer playing. If LIVE RECORD-
ING mode is active and [RECORD] is pressed, GRID RECORDING mode will be activated.
4. Press [STOP] to stop both recording and playback of the sequencer.
To exit LIVE RECORDING mode while keeping the sequencer playing, press [PLAY].
