ELEKTRON Digitakt [65/70] Technical information
![ELEKTRON Digitakt [65/70] Technical information](/views2/2007940/page65/bg41.png)
19. TECHNICAL INFORMATION
65
19. TECHNICAL INFORMATION
ELECTRICAL SPECIFICATIONS
Impedance balanced audio outputs
Main outputs level: +22 dBu peak
Output impedance: 440 Ω unbalanced
Digital S/N ratio: 108 dB (20–20.000 Hz)
Headphones output
Headphones out level: +22 dBu peak
Output impedance: 55 Ω
Audio inputs
Input level: +19 dBu peak
Audio input impedance: 11 kΩ
Digital S/N ratio: 110 dB (20–20.000 Hz)
Unit power consumption: 7 W typical
Compatible Elektron power supply: PSU-3b
HARDWARE
128 × 64 pixel OLED screen
MIDI In/Out/Thru with DIN Sync out
2 × 1/4” impedance balanced audio out jacks
2 × 1/4” audio in jacks
1 × 1/4” stereo headphone jack
48 kHz, 24-bit D/A and A/D converters
Electrically isolated hi-speed USB 2.0 port
Power inlet: Center positive 5.5 × 2.5 mm barrel jack,
12 V DC, 1 A
PHYSICAL SPECIFICATIONS
Sturdy steel casing
Dimensions: W 215 × D 176 × H 63 mm
(8.5” × 6.9” × 2.5”) (including knobs and feet)
Weight: approximately 1.45 kg (3.2 lbs)
100 × 100 mm VESA mounting holes. Use M4 screws
with a max length of 7 mm.
Maximum recommended ambient operating
temperature: +40˚C (+104˚F)
20. CREDITS AND CONTACT INFORMATION
CREDITS
PRODUCT DESIGN AND DEVELOPMENT
Oscar Albinsson
Ali Alper Çakır
Oscar Dragén
Magnus Forsell
Anders Gärder
Fabian Hundertmark
Christer Lindström
Jimmy Myhrman
Jon Mårtensson
David Revelj
Mattias Rickardsson
ADDITIONAL DESIGN
Johan Damerau
Ufuk Demir
Thomas Ekelund
Simon Mattisson
Olle Petersson
Cenk Sayınlı
DOCUMENTATION
Erik Ångman
CONTACT INFORMATION
ELEKTRON WEBSITE
http://www.elektron.se
OFFICE ADDRESS
Elektron Music Machines MAV AB
Sockerbruket 9
SE-414 51 Gothenburg
Sweden
TELEPHONE
+46 (0)31 743 744 0
