APPENDIX A: MIDI
66
APPENDIX A: MIDI
This appendix lists the CC and NRPN specification for the Digitakt.
A.1 TRACK PARAMETERS
TRACK
Parameter CC MSB CC LSB NRPN MSB NRPN LSB
Solo 93 1 102
Mute 94 1 101
Track level 95 1 100
A.2 TRIG PARAMETERS
TRIG PARAMETERS
Parameter CC MSB CC LSB NRPN MSB NRPN LSB
Note 3 3 0
Velocity 4 3 1
Length 5 3 2
Filter Trig 13
LFO Trig 14
A.3 SOURCE PARAMETERS
SOURCE
Parameter CC MSB CC LSB NRPN MSB NRPN LSB
Tune 16 1 0
Play mode 17 1 1
Bit reduction 18 1 2
Sample slot 19 1 3
Start 20 1 4
Length 21 1 5
Loop position 22 1 6
Sample level 23 1 7
A.4 FILTER PARAMETERS
FILTER
Parameter CC MSB CC LSB NRPN MSB NRPN LSB
Filter Frequency 74 1 20
Resonance 75 1 21
Filter Type 76 1 22
Attack Time 70 1 16
Decay Time 71 1 17
Sustain Level 72 1 18
Release Time 73 1 19
Env. Depth 77 1 23
A.5 AMP PARAMETERS
AMP
Parameter CC MSB CC LSB NRPN MSB NRPN LSB
Attack Time 78 1 24
