American DJ® - www.americandj.com - Vizi Wash LED 108 Instruction Manual Page 30
Vizi Wash LED 108 Editing Program
3. Tap the UP button until “REC” is displayed.
4. The display shows “RE.XX”, “XX” stands for the scene
number in the internal memory of where your scenes from the
controller will be stored.
5. Press the UP or DOWN button to select your desired scene
number.
6. Press ENTER to conrm, and the xture will record the
scenes from the external controller.
7. Press MODE/ESC to return to the main menu.
RUN With the function “RUN”, you can run your pre-made
program. You can set the number of steps under Step (S-01
- S-48). You can edit the individual scenes under SEPR.
1. Access the main menu.
2. Tap the UP button until “EDIT” is displayed, press ENTER.
3. Tap the UP button until “RUN” is displayed, press ENTER.
4. Press either UP or DOWN, to select “ON” or “OFF”. To run
your program select “On” and press ENTER to conrm.
5. Press MODE/ESC to return to the main menu.
American DJ® - www.americandj.com - Vizi Wash LED 108 Instruction Manual Page 29
EDIT - This menu item allows you to write a program into the
memory (EEPROM) via the control panel or via the external
controller. Please see pages 31-33 for detailed instructions.
STEP (S-01 - S-48) - With this function you can program
the number of steps in your individual Program.
1. Access the main menu.
2. Tap the UP button until “EDIT” is displayed, press ENTER.
3. Tap the UP button until “STEP” is displayed, press ENTER.
4. The display shows “S-01”, this stands for the rst step of
your program. You can call up to 48 scenes in “Run”. For exam-
ple, if “S-05” is displayed, it means that “Run” will run the rst
5 scenes you saved in “Edit”.
5. Press ENTER to save and press MODE/ESC to exit.
SCXX (SC01 - SC30) - With this function you can choose
the number of scenes in your Program.
1. Access the main menu.
2. Tap the UP button until “EDIT” is displayed, press ENTER.
3. Tap the UP button until “SC01” is displayed.
4. The display shows “SC01”, this stands for the rst scene of
your program. You can call up to 48 scenes. For example, if
“SC05”, it means that “Run” will run the rst 5 scenes you saved
in “Edit”.
5. Press ENTER to save and press MODE/ESC to exit.
REC - With this function you can record the scenes auto-
matically for the external controller.
1. Access the main menu.
2. Tap the UP button until “EDIT” is displayed, press ENTER.
Vizi Wash LED 108 Editing Program
