5
ENGLISH
ENGLISH
q Track, minute, second and frame
displays
• These displays indicate current position
information.
w Time mode indicators
• When the TIME button is pushed, the Time
mode indicator switches as follows:
ELAPSED:
Track’s elapsed time is displayed.
REMAIN:
Track’s remaining time is displayed.
T. ELAPSED:
The total elapsed time of disc is displayed.
T. REMAIN:
The total remaining time of disc is displayed.
e Play mode indicators
• When SINGLE indicator lights up, playback will
finish at end of current track.
• When CONT. indicator lights up, playback
continues until the end of the disc.
r BPM indicator
• Lights up when the BPM is displayed on the
pitch display.
t MP3 indicator
• Lights up when an MP3 disc is detected.
y Loop mode indicators
• DN-S3500 has Loop mode indicators which
consist of A , B and two arrows. A and B marks
indicate A and B points have been set.
•Two arrows indicate loop setting mode as
follows.
or Left arrow only on:
Hot Start mode
Both arrows on:
Seamless Loop mode
, Both arrows flashing:
Seamless Loop Playing
, Left arrow on, right flashing:
Exit play from Seamless Loop
u MP3 file search mode indicators
FILE:
FILE indicator appears in the display, when in
the FILE name search mode.
FOLDER:
FOLDER indicator appears in the display,
when in the FILE & FOLDER name search
mode.
TITLE:
TITLE indicator appears in the display, when
in the TITLE name search mode.
ARTIST:
ARTIST indicator appears in the display, when
in the ARTIST name search mode.
q w e r
!2
!1
y
!
0
iu
t
o
y
(4) Display
i Character display
•You can select the mode or function using
PARAMETERS knob following the short
message which is displayed on the character
display area.
• The character display indicates the operation,
mode name, data, etc., and displays such guide
messages as “Push/Play” means if “YES”,
push PARAMETERS knob. The display indicates
and marks sometime, note that
mark says you to turn PARAMETERS knob and
marks says to push PARAMETERS knob.
• The PARAMETERS LED flashes when you can
use PARAMETER knob, otherwise this knob
used for Track Selection.
o Play Position indicators
• Play position indicator:
The 30 dots indicate a visual track position
marker during normal play. The 10 Orange dots
indicate the play position during the reverse play
mode.
• End of Message:
When the time remaining to the end of the track
is less than the specified time, the EOM (End Of
Message) play position indicator flashes along
with the remaining time, notifying of the track
end.
✽The EOM time can be set in the presets.
!0 KEY ADJ. indicator
• KEY ADJ. indicator appears in the display when
the Key Adjust mode is ON.
!1 MEMO indicator
• MEMO indicator appears in the display when
there is a memo setting found for the current
playing track or the track at which the Cue
standby mode is currently set.
!2 Pitch display
• This indicator display the playback speed (pitch).
