![Denon Denon DN-S3500 [12/134] English](/views2/2009458/page12/bgc.png)
6
ENGLISH
ENGLISH
5
BASIC OPERATION
Play and pause
•When the o CUE button is pushed during playback,
the track stops and returns to the original position of
which playback started from, the (Cue point). This
function is also called Back-Cue. With the Back-Cue
function, you can start from exactly same position.
The o CUE button illuminates solid red when DN-
S3500 is ready to start playback.
•You can set and change Cue point as follows.
• When you started playback.
•Track select finished.
• manual search.
Play and Cue
•
If you would like to start playback other from the
beginning of the track, you can move the Cue Point
using fast Search or the manual frame search function.
4
After you have found your
preferred Cue point, push
the o CUE button then a
new Cue point is set.
2
3
Turn the !0 Scratch Disc to
change Cue point. You can hear
the short sound of the current
Cue point.
CUE
•Turn the @7 TRACK knob.
• By pushing @7 TRACK knob down while turning, the
tracks will increment 10 at a time.
Select the track
Move the Cue point
1
You can move to the approximate playback
start position by @9 or #0 FAST SEARCH
buttons.
QUICK JUMP
• If the FAST SEARCH button is
tapped shortly, the playback
position jumps about 10
seconds.
The jump time can be selected in the preset
mode from 10, 20, 30 or 60 sec.
FAST SEARCH
• When the FAST SEARCH button is pressed
and held in, the disc is fast-searched.
QUICK JUMP
FAST SEARCH
•
Each push of the u PLAY/PAUSE (13) button
switches between playback and pause. PLAY/PAUSE
(
13) button illuminates solid green during playback
and flashs in pause.
•When the u PLAY/PAUSE (13) button is pushed
during play, the DN-S3500 pauses playback at that
point. Push u PLAY/PAUSE (
13) button once again
and playback resumes.
• When the Platter mode is set to MAIN, the Platter
turns when the Main Track is played. When the
rotation of the Scratch Disc is stopped by your hand,
the sound pauses, and when your hand is released
playback resumes.
When the !0 Scratch Disc is turned in the
pause, Cue or frame repeat mode, it works as
the manual frame search function.
Push the #6 PLATTER SOURCE
button to set !0 Scratch Disc to
search mode. The PLATTER
SOURCE button LEDs will turn
off and the display will indicate
“FRAME Search”.
SOURCE
4
COMPACT DISCS
1. Precautions on handling compact discs
• Do not allow fingerprints, oil or dust to get on the surface of the disc.
If the disc is dirty, wipe it off with a soft dry cloth.
• Do not use benzene, thinner, water, record spray, electrostatic-proof chemicals, or silicone-treated cloths to
clean discs.
•
Always handle discs carefully to prevent damaging the surface; in particular when removing a disc from its
case or returning it.
• Do not bend the disc.
• Do not apply heat.
•Do not enlarge the hole in the center of the disc.
• Do not write on the label (printed side) with a hard-tipped implement such as a pencil or ball point pen.
• Condensation will form if a disc is brought into a warm area from a colder one, such as outdoors in winter.
Do not attempt to dry the disc with a hair dryer, etc.
2. Precautions on storage
• After playing a disc, always unload it from the player.
• Always store the disc in the jewel case to protect from dirt or damage.
• Do not place discs in the following areas:
(1) Areas exposed to direct sunlight for a considerable time.
(2) Areas subject to accumulation of dust or high humidity.
(3) Areas affected by heat from indoor heaters, etc.
