17
ENGLISH
ENGLISH
(15) MEMO ALL COPY :
Copy all MEMO data from the master unit of DN-S3500 (or DN-S3000 DN-S5000, DN-D9000) to the
slave unit of DN-S3500 (or DN-S3000 DN-S5000, DN-D9000) when both unit are connected by the
normal 3.5 mm min stereo Cable. (See diagram for the cable.)
NOTE: Be sure CD player have no discs inside.
A straight cable used:
• Using the 3.5 mm cable, connect the MEMO terminals between two DN-S3500 units or between one
DN-D9000 and one DN-S3500 unit or between one DN-S5000 and one DN-S3500 unit or between one
DN-S3000 and one DN-S3500 unit.
• Copying can be performed using the DN-S3500 and DN-D9000 or the DN-S3500 and DN-S3000 or the
DN-S3500 and DN-S5000 in the same way as when using two units of the DN-S3500.
DN-S3500
MEMO OUT
DN-S3500 (MEMO IN)
DN-S3000 (X’EFFECT IN)
DN-S5000 (X’EFFECT IN)
DN-S3500
MEMO IN
DN-S3500 (MEMO OUT)
DN-D9000 (X’EFFECT)
• Perform the copying operation as below on the slave unit of DN-S3500.
q To start copying, push the PARAMETERS knob and select “YES”. Now “Memo Copy?” messages
flashes on the character display.
w Push the PARAMETERS knob again to confirm. Now “Copy OK?” is displayed.
e Push the PARAMETERS knob once again, and the unit starts copying when the MEMO data are
received from the master unit. “Now Copying” is displayed.
• If the master unit and the slave unit are not connected properly or the DN-2600F is not prepared
to start sending data, “Not Connect” is displayed on the character display.
r When copying is completed correctly, “Complete!” is displayed.
• “Copy Error” is displayed on the character display if copying was not completed correctly.
• “Not connect” is displayed on the charactor display if it is not possible to communicate normally.
In this case, try the above procedure again.
• The copied MEMO data are added to the highest number area of the slave DN-S3500 unit.
(16) Version No. : The DN-S3500’s software version is displayed. (SYSTEM / DSP)
(17) PRESET INITIALIZE : Set all the preset data back to the factory defaults.
q To clear the PRESET data, push the PARAMETERS knob.
“Preset Int?” flashes on the character display.
w Push the PARAMETERS knob again.
“Preset Initial!” is displayed on the character display while data clearing.
e Once clearing is completed, “Complete!” is displayed.
15
PRESET
1. Preset mode
q The preset mode is available when @4 PRESET button is pushed for more than 1 sec while the DN-S3500
is in Cue, pause or no disc mode.
w Turn the @7 PARAMETERS knob to select the preset item.
e After selecting an item, push the @7 PARAMETERS knob to select the preset data.
r To change other Preset items, repeat these steps.
t Push the @4 PRESET, o CUE or u PLAY / PAUSE (
13) button to exit from the Preset mode.
2. Preset items and data
The “*” mark next to the data indicates the default value.
(1)
Cue Mode : DENON* (When the playback is started durnig the Play Pause mode, the Cue point is set.) /
Other (When the Cue button is pushed during the Play Pause mode, the Cue point is set.)
(2) Auto Cue : Auto Cue level search on/off. (ON* / OFF)
(3) Next Tr Time : OFF / 1sec / 2sec* / 3sec
Select the time for fading out the currently playing track when playback of a new track is started with
the next track function.
(4) Platter Speed : 33rpm* / 45rpm
Select the rotational speed on the platter.
(5) 3/4 Effect : OFF* / ON
You can use 3/4 beat effects when you select the Echo & Flanger parameter for the effector.
(6) Jump Time : 10sec* / 20sec / 30sec / 1min
Select the jump time of Quick Jump.
(7) Pitch Range : ±4% / ±10%* / ±16% / ±24%
Select the playing pitch range when the power is turned on.
(8) EOM Time : Track end warning message alert time.
(OFF / 10sec* / 15sec / 20sec / 30sec / 60sec / 90sec)
(9) Fader Mode (FADER START MODE) : Play / Cue* / P / Pause
Select 2-line type (Play and Cue) or 1 line type (Play and Pause).
(10) Power On Play : ON / OFF*
Playback starts when the power is turned on if a disc is loaded.
(11) Pitch : Pitch ON* / Key AdjON (KEY ADJUST ON) / Pitch OFF
Select the pitch mode when the power is turned on.
(12) Play Mode (SINGLE / CONTINUOUS / SINGLE PLAY LOCK) : Single / Cont. / Play Lock*
Select the play mode when the power is turned on.
(13) Time Mode : Elapsed* / Remain / T.Elapsed / T.Remain
Select the time mode when the power is turned on.
(14) MEMO ALL CLEAR :
Clear all MEMO data in the non-volatile memory.
q To clear all MEMO data, push the PARAMETERS knob.
• “Memo Clr?” flashes in the character display.
w Push the PARAMETERS knob again and select “Yes” to execute clearing all MEMO data.
• “Now Clearing!” is displayed on the character display while clearing.
e Once clearing is completed, “Complete!” is displayed.
POWER ON OFF
DIGITAL OUT
L
R
LINE OUTFADER IN OUT
MEMO
POWER ON OFF
DIGITAL OUT
L
R
LINE OUTFADER IN OUT
MEMO
MEMO IN jack
DN-S3500-1 DN-S3500-2
MEMO OUT jack
3.5 mm stereo mini cord
