Faber ZOOM PLUS 345.0492.568 [10/36] Components nest models
![Faber ZOOM PLUS 345.0492.568 [10/36] Components nest models](/views2/2013990/page10/bga.png)
EN
1
0
10
Components (Nest models)
Ref. Q.ty Product Components
1 1 Hood Canopy complete with: Controls, Light, Filters, Motor.
2 1 Hood support Plate (with lamp holder)
2.1 2 Hood support plate extension
4 1 Cable raceway
5 4 Glass (Glass products manually)
14 1 Pawl
Ref. Q.ty Installation Components
7.1 8 Glass fixing brackets with bush
11 10 Wall plugs ø 10
12h 10 Screws M5 x 70
12d 24 M4 Nut (fixing Brackets to Plate extension)
12e 8 Glass fixing knobs
12f 8 Glass protection gaskets
12g 1 Screw for pawl
12h 8 Glass protection gaskets
Q.ty Documentation
1 Instruction Manual
Содержание
- Instruction manual 1
- Installation 3
- Recommendations and suggestions 3
- Maintenance 5
- Characteristics 6
- Components chic vanilla models 8
- Components nest models 10
- Components vertigo model 12
- En 1 2 12
- En 1 3 13
- Components kaleidos model 14
- En 1 5 15
- Components luxia model 16
- En 1 6 16
- En 1 7 17
- En 2 0 20
- Fitting the limiter pawl 20
- Installation 20
- Ceiling shelf drilling and plate fixing 21
- En 2 1 21
- En 2 2 22
- En 2 3 23
- N b before continuing with installation it is necessary to move the hood to a height of at least 650 mm from the cooker hob using a support or the assistance of another person this is essential as the hood cables must necessarily be connected to the plate fitted to the ceiling without the weight of the hood bearing on the structure 23
- En 2 4 24
- En 2 5 25
- En 2 6 26
- Warning 26
- Connections 27
- En 2 7 27
- En 2 8 28
- En 2 9 29
- En 3 0 30
- En 3 1 31
- Control panel 32
- En 3 2 32
- Remote control the appliance can be controlled using a remote control powered by a 1 v carbon zinc alkaline batteries of the standard lr03 aaa type not included do not place the remote control near to heat sources used batteries must be disposed of in the proper manner 32
- En 3 3 33
- Maintenance 33
- En 3 4 34
- Lighting unit 34
- Lighting unit lamps 34
- Additional information for the installation technician 35
- En 3 5 35
- Procedure to be used in case of malfunction on the movement 35
