RECOMMENDATIONS AND SUGGESTIONS

The Instructions for Use apply to several versions of this appliance.

Accordingly, you may find descriptions of individual features that do not

apply to your specific appliance.

INSTALLATION

• The manufacturer will not be held liable for any damages resulting from

incorrect or improper installation.

• The minimum safety distance between the cooker top

and the extractor hood is 650 mm (some models can be

installed at a lower height, please refer to the paragraphs

on working dimensions and installation).

• Check that the mains voltage corresponds to that

indicated on the rating plate fixed to the inside of the hood.

• For Class I appliances, check that the domestic power supply guarantees

adequate earthing.

Connect the extractor to the exhaust flue through a pipe of minimum

diameter 120 mm. The route of the flue must be as short as possible.

•

Do not connect the extractor hood to exhaust ducts carrying combustion

fumes (boilers, fireplaces, etc.).

• If the extractor is used in conjunction with non-electrical appliances (e.g. gas

burning appliances), a sufficient degree of aeration must be guaranteed in

the room in order to prevent the backflow of exhaust gas. The kitchen must

have an opening communicating directly with the open

air in order to guarantee the entry of clean air. When

the cooker hood is used in conjunction with appliances

supplied with energy other than electric, the negative

pressure in the room must not exceed 0,04 mbar to

prevent fumes being drawn back into the room by the

cooker hood.

• The air must not be discharged into a flue that is used for exhausting fumes

from appliances burning gas or other fuels (not applicable to appliances that

only discharge the air back into the room).

• In the event of damage to the power cable, it must be replaced by the

manufacturer or by the technical service department, in order to prevent any

risks.
