Additional information for the installation technician
• Open the lighting unit by pulling on the notch provided.
• Apply the label, indicated the type of lighting, on the Hood as indicated in the figure
(Rif. A).
A
B
Procedure to be used in case of malfunction on the movement
1. Check that the fuse is properly inserted and that it has not burned out, for
replacing the fuse open the lighting unit and unscrew the fuser holder and
replace it with one having the same characteristics (Rif. B)
2. Check that the hood canopy is fitted level (the use of a spirit level is
recommended).
3. Check that the four cables are all at the same tension. The front left cable
must not be slacker than the others.
If even these operations do not solve the problem contact the Technical Assistance.
