EN
3
2
32
REMOTE CONTROL
The appliance can be controlled using a remote control
powered by a 1.5 V carbon-zinc alkaline batteries of the
standard LR03-AAA type (not included).
• Do not place the remote control near to heat sources.
• Used batteries must be disposed of in the proper
manner.
Control panel
Button
Function
Display
Turns the Motor On/Off. -
Hood Closed:
- Press the button briefly to start lowering the hood
- It will stop when the button is pressed again.
When the movement has been completed the motor will start at speed 2.
-
Hood Open:
- Press and hold for 2 seconds to activate raising of the hood, which stops when it reaches the stop.
- Press (briefly) to stop the movement (before the stop is reached).
- Press again briefly to turn the motor on/off.
- Press and hold for 2 seconds to start raising of the hood.
-
I
f the motor is on, it will first stop the motor and then start the movement.
-
Decreases the speed of the Motor. -
Increases the speed of the Motor. -
INTENSIVE
- This can only be activated with the hood lowered and when the delay or 24h functions are not active.
- Activates Intensive speed from any other speed.
To disable it, simply press the same button again or turn the motor off.
- Intensive speed is timed to run for 6 minutes. At the end of the 6 minutes the system will automatically
return to the speed that was set before.
The led on the motor
button (on the hood
controls) will flash
once a second.
Press briefly for the Delay Function:
Can only be activated if the Intensive or 24h function is not active.
Activates and deactivates total shutdown of the hood (motor+lights) after 30 minutes:
To disable the Delay, simply press the button again or turn the motor off.
The led on the motor
button (on the hood
controls) will flash
once every 0.5
c
onds.
Press and hold for 2 sec. for the 24H Function:
Can only be activated if the Intensive or Delay function is not active.
Activates and deactivates the 24H function for 10 minutes every hour, for 24 hours. After this time it is
deactivated.
The led on the motor
button (on the hood
controls) will flash
once every 2 seconds.
Turns the Hood lights On/Off.
