ADJ Products, LLC - www.adj.com - Hydro Beam X1 User Manual Page 10
Hydro Beam X1 Overview
1. Lens
2. MENU Button
3. ENTER Button
4. LCD Menu Control Display
5. DOWN Button
6. UP Button
7. Service Port
8. IP65 5-Pin DMX IN & IP65 5-Pin DMX OUT
9. Gore Valve
10. IP65 Power IN & IP65 Power Out
3 4 5
8
6
7 9
10
1
2
3 4 5
8
6
7 9
10
1
2
