ADJ Products, LLC - www.adj.com - Hydro Beam X1 User Manual Page 19

Hydro Beam X1 Fixture Installation

The Hydro Beam X1 is fully operational in three dierent mounting positions, hanging upside-down,

mounted sideways on trussing, or set on a at level surface. Be sure this xture is kept at least 12m

(40ft) away from any ammable materials (decoration etc.). Always use and install the supplied safety

cable as a safety measure to prevent accidental damage and/or injury in the event the clamp fails

(see next page). Never use the carrying handles for secondary attachment.

When installing the unit, the trussing or area of installation must be able to hold 10 times the weight

without any deformation. When installing the unit must be secured with a secondary safety attachment,

e.g. and appropriate safety cable. Never stand directly below the unit when mounting, removing, or

servicing the unit.

Overhead mounting requires extensive experience, including calculating working load limits, installation

material being used, and perodic safety inspection of all installation material and unit. If you lack

these qualications, do not attempt the installation yourself.

These installaiton should be checked by a skilled person once a year.

* S A FETY CABL E

ALWAYS ATTACH A SAFETY CABLE WHENEVER

INSTALLING THIS FIXTURE IN A SUSPENDED

ENVIRONMENT TO ENSURE THE FIXTURE WILL

NOT DROP IF THE CLAMP FAILS.

* S I D E M OUNT I N G

TO MAINTAIN IP65 RATING INTEGRITY, FIXTURE

MUST BE INSTALLED WITH CABLES FACING THE

GROUND AT ALL TIMES. WATER MUST EASILY

RUN OFF AND NOT COLLECT AROUND CABLE

CONNECTIONS.

CABLES

DOWN

CABLES

DOWN

LCD DISPLAY
