ADJ Hydro Beam X1 [14/40] Lamp installation replacement
![ADJ Hydro Beam X1 [14/40] Lamp installation replacement](/views2/2014316/page14/bge.png)
ADJ Products, LLC - www.adj.com - Hydro Beam X1 User Manual Page 13
2. Unscrew the (4x) allen head screws to remove the rear cover. When removing the rear cover,
please be advised that the cover is connected to the unit via a safety cable and connected wire
cable.
Hydro Beam X1 Lamp Installation
LAMP INSTALLATION/REPLACEMENT
WARNING! LAMP REPLACEMENT SHOULD ONLY BE DONE BY A TRAINED TECHNICIAN.
1. Turn OFF power and allow approximately 60 minutes for the xture to cool down.
4. Use a at head screwdriver to turn the
lamp centering screw clockwise until the lamp
slides out of its holding mechanism on the
right side.
3. Gently remove the (2x) spade terminals
connected to the lamp.
