Hydro Beam X1 WiFly Control

BEFORE SETTING THE WIRELESS CHANNEL ON ANY WIFLY FIXTURE, MAKE SURE

THE SOURCE WIFLY WIRELESS DMX TRANSCEIVER DEVICE IS OFF.

With this feature you are able to control the unit with DMX without the need of XLR cables. Your

DMX controller must be connected to a ADJ WiFly Transceiver to use this function. You are able to

communicate up to 2500 feet/760 meters (open line of sight).

1. Ensure the source WiFly wireless DMX Transceiver device is powered OFF.

2. Power ON the fixture and using the control panel scroll to the PERSONALITY menu and press

ENTER. Use the UP and DOWN buttons to highlight the WIFLY SETTINGS submenu and press

ENTER.

3. Using the UP and DOWN buttons, highlight ENABLE/DISABLE WIFLY. Press the ENTER button

to toggle between ENABLE & DISABLE. Press ENTER so that “ENABLE” is displayed.

4. Next highlight SET WIFLY CHANNEL and press ENTER. Use the UP and DOWN buttons to find

your desired WiFly address and press ENTER to confirm.

NOTE: Erratic fixture movement may occur if other WiFly wireless DMX products are in use in

the same area and are using the same WiFly wireless channel. When WiFly is enabled, the fixture

may immediately start to respond to the DMX wireless signal from another WiFly wireless DMX

Transceiver. Make sure to know what WiFly wireless channels are being used in the area where the

fixture is being used.

ADJ WIFLY WIRELESS TRANSCEIVER only has 0-14 wireless channels, NO CH 15.

5. Press the MENU button to exit out of the WIFLY SETTINGS submenu. Press the UP button so

that SELECT SIGNAL is highlighted and press ENTER. Press the DOWN button to highlight

WIFLY and press ENTER. Select YES and press ENTER to confirm.

6. Set your desired DMX address in the DMX ADDRESS submenu of the DMX SETTINGS main system

menu. Set your desired DMX channel mode in the DMX CH MODE submenu of the DMX SETTINGS

main system menu.

7. Repeat this process for all WiFly compatible fixtures in the WiFly wireless network, making sure

all fixtures are assigned the same WiFly wireless channel.

8. After all fixtures in the WiFly wireless network have been set to the same WiFly wireless channel

and powered ON, power ON the source WiFly DMX Transceiver device.

4. Test all fixtures connected to the WiFly wireless network to confirm proper functionality.
